Determination of the Vegetative Phase Critical for Monitoring Wheat Nitrogen Status Tropical Through Digital Color Analysis and Index Camera Reflectance
DOI:
https://doi.org/10.58812/wsa.v4i02.2802Keywords:
Nitrogen Monitoring, Tropical Wheat, Digital Image Analysis, RGB Vegetation Indices, Growth Stage DependencyAbstract
Reliable nitrogen (N) monitoring remains a major challenge in tropical wheat systems due to dynamic N uptake, redistribution, and environmental variability across growth stages. Although RGB based digital imaging offers a rapid and non-destructive alternative, its accuracy is often limited by the phase-dependent relationship between leaf color and nitrogen status. This study aimed to identify the critical vegetative stage that provides the most reliable estimation of leaf nitrogen in tropical wheat (Triticum aestivum L.). A greenhouse experiment was conducted using a randomized block design with five nitrogen rates (0–300 kg urea ha⁻¹). Leaf images were collected at four vegetative stages (V1–V4), and RGB values were transformed into vegetation indices (ExG, GLI, TGI, and NGRDI). These indices were correlated with chlorophyll and leaf nitrogen content using Pearson analysis. Results showed a clear phase-specific pattern, with the strongest relationship observed at V3 (second node emergence). The ExG index exhibited a very strong and significant correlation with leaf nitrogen (r = 0.97; p < 0.01). In contrast, weak correlations at V1 and negative trends at V4 were associated with limited nitrogen accumulation and remobilization processes.These findings highlight V3 as the optimal stage for nitrogen estimation and emphasize the importance of a phase-specific approach to improve RGB based monitoring in tropical wheat systems.
References
[1] T. Antal et al., “Acclimation of photosynthesis to nitrogen deficiency in Phaseolus vulgaris,” Planta, vol. 232, pp. 887–898, 2010.
[2] F. Azima, N. Novelina, and R. S. Pane, “The physical and chemical properties of wheat flour in some wheat (Triticum spp.) varieties grown in West Sumatra,” Int. J. Adv. Sci. Eng. Inf. Technol., vol. 3, no. 4, pp. 303–308, 2013.
[3] S. Cai et al., “Evolutionary conservation of ABA signaling for stomatal closure,” Plant Physiol., vol. 174, no. 2, pp. 732–747, 2017.
[4] L. H. Chen, M. Xu, Z. Cheng, and L. T. Yang, “Effects of nitrogen deficiency on photosynthesis, chlorophyll fluorescence, and antioxidant system in rice,” Int. J. Mol. Sci., vol. 25, no. 19, p. 10409, 2024.
[5] F. Diekmann, “Wheat,” J. Agric. Food Inf., vol. 10, no. 4, pp. 289–299, 2009.
[6] M. Esfahani et al., “Improvement of nitrogen management in rice paddy fields using chlorophyll meter (SPAD),” Paddy Water Environ., vol. 6, pp. 181–188, 2008.
[7] B. M. Farid et al., “Evaluation of several tropical wheat genotypes under various water availability,” IOP Conf. Ser.: Earth Environ. Sci., vol. 486, p. 012093, 2020.
[8] Y. Fu et al., “Winter wheat nitrogen status estimation using UAV-based RGB imagery,” Remote Sens., vol. 12, no. 22, p. 3778, 2020.
[9] R. C. Gonzalez and R. E. Woods, Digital Image Processing, 2nd ed. Pearson, 2002.
[10] D. A. Goulding, P. F. Fox, and J. A. O’Mahony, “Milk proteins: An overview,” in Milk Proteins, Academic Press, 2020, pp. 21–98.
[11] B. K. Gunturk et al., “Demosaicking: Color filter array interpolation,” IEEE Signal Process. Mag., vol. 22, no. 1, pp. 44–54, 2005.
[12] T. Haider et al., “A computer-vision-based approach for nitrogen content estimation in plant leaves,” Agriculture, vol. 11, no. 8, p. 766, 2021.
[13] J. Kang et al., “Physiological mechanisms underlying reduced photosynthesis in wheat under nitrogen deficiency,” Crop J., vol. 11, no. 2, pp. 638–650, 2023.
[14] L. Kong et al., “Excessive nitrogen application dampens antioxidant capacity and grain filling in wheat,” Sci. Rep., vol. 7, p. 43363, 2017.
[15] S. J. Leghari et al., “Modern leaf color chart successfully prepared and used in crop production,” Eur. Acad. Res., vol. 4, no. 2, pp. 900–916, 2016.
[16] C. Li et al., “Morphology and nitrogen uptake of wheat influenced by urea application,” Agronomy, vol. 12, no. 10, p. 2338, 2022.
[17] R. Li et al., “Estimation of nitrogen content in wheat using RGB imaging,” Field Crops Res., vol. 289, p. 108735, 2022.
[18] G. Ma et al., “Determining optimal nitrogen input for wheat yield,” Front. Plant Sci., vol. 10, p. 181, 2019.
[19] R. A. McIntosh, “Wheat genetics,” in Reference Module in Food Science, Elsevier, 2016.
[20] Minolta Camera Co., Ltd., Manual for chlorophyll meter SPAD-502, 1989.
[21] I. Monostori et al., “Relationship between SPAD value and grain yield in wheat,” Euphytica, vol. 211, pp. 103–112, 2016.
[22] H. Noor and S. Min, “Effect of nitrogen rates on wheat yield and quality,” Appl. Ecol. Environ. Res., vol. 18, no. 4, pp. 5701–5726, 2020.
[23] H. Noor et al., “Nitrogen fertilization effects on wheat,” Heliyon, vol. 9, no. 7, p. e18177, 2023.
[24] A. Nur et al., “Genetic improvement of tropical wheat,” J. Agric. Res. Dev., vol. 34, no. 1, 2015.
[25] A. Nur et al., “Genetic diversity of wheat population,” Sci. J. Isotope Radiat. Appl., vol. 10, no. 1, 2016.
[26] N. E. Putri et al., “Wheat adaptation in tropical regions,” SABRAO J. Breed. Genet., vol. 52, no. 4, 2020.
[27] K. G. Rao and N. K. Das, “Leaf color chart for nitrogen management,” Pharma Innov. J., vol. 12, no. 6, pp. 3974–3979, 2023.
[28] S. Ritung et al., Technical Guidelines for Land Evaluation for Agricultural Commodities, 2011.
[29] L. Rosen, P. M. Ewing, and B. C. Runck, “RGB-based indices for nitrogen estimation,” Agron. J., vol. 116, no. 6, pp. 3070–3080, 2024.
[30] P. Shi et al., “Nitrogen estimation using RGB images and machine learning,” Comput. Electron. Agric., vol. 180, p. 105860, 2021.
[31] B. Singh, “Leaf color chart for nitrogen management,” Agric. Res. J., vol. 59, no. 4, 2022.
[32] L. Taiz and E. Zeiger, Plant Physiology. Benjamin/Cummings, 1991.
[33] Y. Wahyu et al., “Adaptability of wheat genotypes in lowlands,” Agrohorti Bull., vol. 1, no. 1, pp. 1–6, 2013.
[34] D. Wang et al., “Excessive nitrogen application effects in wheat,” Acta Agric. Scand., 2011.
[35] J. Wang et al., “Wheat response to low nitrogen stress,” Plants, vol. 8, no. 4, p. 98, 2019.
[36] X. Yue et al., “SPAD for nitrogen status estimation,” Int. J. Plant Prod., vol. 14, no. 1, pp. 67–75, 2020.
[37] H. Yuzhu et al., “Nitrogen determination using RGB image analysis,” Afr. J. Biotechnol., vol. 10, no. 77, pp. 17737–17741, 2011.
[38] M. X. Zhao et al., “Nitrogen accumulation in wheat,” J. Plant Nutr. Fertil. Sci., vol. 12, no. 2, pp. 143–149, 2006.
